CO2 plastic laser engraving machine for leather textile cloth cutting 200W
Introduction
QA200-1530 plastic laser engraving machine is a large gantry type laser cutting and engraving machine for big size products.
Laser cutting engaving is advanced CNC technology and a unique non-contact processing. Laser working without any graphical limits and not produce any mechanical deformation. Laser processing has the advantages of high precision, high speed, no fraying, and high quality results. In addition, applicability of laser processing is more flexible.
Laser can do cutting, engraving, hollowing, punching for a variety of textile, fabrics, garment, leather, shoe, upholstery, carpet, automotive interior, tent, etc. Laser processing technology is more sophisticated, creative and unique.
High quality laser cutting engraving head, drawing as below photo:
Features
1. Large area edge cutting and small area hollowing
2. Spare parts standardization, the same number of parts can be current used for different machine.
3. Blade surface and shell side surface at the same height,it's more convenient for up-down loading
4. Laser cover with the laser head outside. Convenient for the operator to monitor the process at real-time
5. large format laser cutting cut smooth fine, to meet customer demand for cutting and engraving industry
6. Leading pattern digitizing technology
7. Standardized production line in laser industry.
8. 80-150W CO2 laser tube to choose
9. Laser work, support Coreldraw, AutoCAD
Specification
| Laser power | 200W |
| Laser type | CO2 glass tube |
| Cutting area | 1500mm x 3000 mm |
| Max. Object size | 1500mm(no limited) |
| Max. cutting thickness | Acrylic 0-30mm |
| Orientation precision | 0.05mm |
| Repeating orientation precision | 0.02mm |
| Max. movement speed | 15M/MIN |
| Cooling system | Water cooling |
| Power | 220V/50HZ/(35A/40A) |
| Average power consumption | 12.5KW |
Materials
| Items | Engraving | Cutting |
| Fabric Denim , leather , polyester , cotton , nylon , pongee , suede , jeans ,satin , corduroy , chiffon , tulle , fleece | yes | yes |
| Wood Plywood , bamboo , veneer , mdf , polymeric materials | yes | yes |
| Plastic PP , plastic , ABS plastic , PVC , pipe , polyester , sheet , insulation layer | yes | yes |
| Organic Acrylic , rubber , resin , epoxy | yes | yes |
| Paper Packaging materials , tin foil , card , cardboard , chipboard | yes | yes |
| Composite Double color plate organic board | yes | yes |
| Stone Ceramic , tile , marble ,granite , slate , gravestone , porcelain , tombstone , ceramic plate | yes | no |
| Other Nonmetals process materials , coating materials , plating materials , spraying materials | yes | no |
Applications
Applicable Materials: Wood, Acrylic, Veneer, Plywood, MDF, Leather, Glass, Plastic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Bamboo, ABS Double Color Board, Organic Glass, PVC, Paper, Paperboard, Cardboard, Marble, Bamboo, Balsa, Rubber Sheet, etc.
Applicable Industries: Furniture Marquetry, Promotional Items, Plaques, Trophies, Awards, Precise Ornaments, Souvenirs, Nameplates, Models, Architectural Models, Furniture, etc.
Samples
Configuration
Machine overlook
5 Stars Reviews from Customers:
FAQ:
1 Q: What is the warranty of the laser cutting machine?
A: 1 years` warranty and whole life after-sale service.
2 Q: What is your payment terms?
A: T/T, L/C, Westen Union, etc.
3 Q: What is your after-sale service?
A: Engineers can offer oversea services and we can also offer online service for little problems,
using online chatting tools like Whatsapp to talk with customers directly for all questions .
4 Q: How is the quality of the machines?
A: Germany high technoloy with good quality.
5 Q: How is the operation of the machine?
A: We can also send engineers to your factory for training. Or you can send worker to gain training in our factory directly.
We offer operation manual and videos, show you how to operate the machine.
